047301.5PARL
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Circuit Protection / Fuses
Description
Fuses with Leads (Through Hole) 125V PICO II SB AMMO ROHS 1.5A
PDF
/
Inventory: 10048
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Box (TB)
Series PICO? II 473
Size / Dimension 0.135Diax0.280L 3.43mmx7.11mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Axial
Resistance 116mOhm
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Voltage - Rated DC 125V
Current Rating (Amps) 1.5A
Current Rating 1.5A
Voltage - Rated AC 125V
Approval Agency CSA, PSE, UR
Response Time Slow Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 50A
Melting I2t 3.94
DC Cold Resistance 0.116Ohms
Dimensions
Length 7.112mm
Compliance
RoHS Status ROHS3 Compliant
