047001.5DRSNP
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Circuit Protection / Fuses
Description
FUSE BRD MNT 1.5A 125VAC/DC 1206
PDF
/
Buying Options
Total Price: USD $1.09
Unit Price: USD $1.0912
≥1 USD $1.0912
≥10 USD $1.05776
≥100 USD $0.99
≥500 USD $0.819456
≥1000 USD $0.68288
≥3000 USD $0.665843
Inventory: 1167
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Body Height 1.17mm
Technical
Rated Voltage(DC) 125V
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.1263Ohm
Melting I2t 0.4597
Rated Current 1.5A
Breaking Capacity @ Rated Voltage 50A
Fuse Type Board Mount (Cartridge Style Excluded)
Response Time Fast Blow
Physical Dimension 3.3mm x 1.57mm x 1.17mm
Body Breadth 1.57 mm
Body Length or Diameter 3.3mm
Approval Agency cULus, PSE
Voltage - Rated AC 125V
Reference Standard UL
Packing Method TR
Current Rating (Amps) 1.5A
Additional Feature PRE ARCING TIME: OPEN WITHIN 5 SEC AT 200% RATED CURRENT
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.124Lx0.059W x 0.045 H 3.15mmx1.50mmx1.15mm
Series NANO2?470
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
