046701.5NR
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Circuit Protection / Fuses
Description
FUSE BOARD MNT 1.5A 32VAC 65VDC
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.2056
≥1 USD $1.2056
≥10 USD $1.16512
≥100 USD $1.08944
≥500 USD $0.901648
≥1000 USD $0.751432
≥3000 USD $0.732618
Inventory: 1097
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Terminal Shape WRAPAROUND
Number of Pins 2
Body Material Thermoplastic
Technical
Operating Temperature -55°C~90°C
Packaging Tape & Reel (TR)
Series 467
Size / Dimension 0.063Lx0.032W x 0.012 H 1.60mmx0.81mmx0.31mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 38.5mOhm
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Composition Thin Film
HTS Code 8536.10.00.40
Voltage - Rated DC 32V
Packing Method TR
Depth 810μm
Current Rating 1.5A
Reference Standard CSA; UL
Voltage - Rated AC 32V
Case Code (Metric) 1608
Approval Agency CSA, UL
Body Length or Diameter 1.6mm
Case Code (Imperial) 0603
Body Breadth 0.813 mm
Physical Dimension 1.6mm x 0.813mm x 0.305mm
Working Voltage 32V
Power Dissipation 121.7mW
Response Time Fast Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 35A AC 13A DC
Melting I2t 0.0766
DC Cold Resistance 0.0385Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic VERY FAST
Fuse Current 1.5A
Trip Time or Delay 14400 s
Fuse Class Supplemental
Dimensions
Height 304.8μm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
