0456020.ER
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, Square End Block
Category Circuit Protection / Fuses
Description
FUSE BOARD MNT 20A 125VAC 100VDC
PDF
/
Buying Options
Total Price: USD $4.22
Unit Price: USD $4.2152
≥1 USD $4.2152
≥10 USD $4.07088
≥100 USD $3.92656
≥500 USD $3.053776
≥1000 USD $2.544784
≥3000 USD $2.472096
Inventory: 1125
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Height 3.05mm
Technical
Fuse Current 20A
Joule Integral-Nom 18 J
Blow Characteristic VERY FAST
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.0023Ohm
Melting I2t 18
Breaking Capacity @ Rated Voltage 100A AC 300A DC
Fuse Type Board Mount (Cartridge Style Excluded)
Response Time Fast Blow
Working Voltage 125V
Body Length or Diameter 10.1mm
Approval Agency cULus, PSE
Voltage - Rated AC 125V
Reference Standard PSE; UL
Current Rating 20A
Depth 3.12mm
Packing Method TAPE AND REEL
Voltage - Rated DC 100V
HTS Code 8536.10.00.40
Resistance 2.3mOhm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 0.398Lx0.123W x 0.123 H 10.10mmx3.12mmx3.12mm
Series NANO2? 456
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Body Material Ceramic
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case 2-SMD, Square End Block
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Silver
Contact Material Brass
Supply Chain
Factory Lead Time 19 Weeks
