0453.250NR
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, Square End Block
Category Circuit Protection / Fuses
Description
FUSE BOARD MNT 250MA 125VAC/VDC
PDF
/
Inventory: 7162
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 2.6924mm
Technical
Trip Time or Delay 14400 s
Blow Characteristic VERY FAST
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.5765Ohm
Melting I2t 0.0158
Breaking Capacity @ Rated Voltage 50A
Fuse Type Board Mount (Cartridge Style Excluded)
Response Time Fast Blow
Physical Dimension 6.1mm x 2.69mm x 2.69mm
Body Breadth 2.69 mm
Body Length or Diameter 6.1mm
Approval Agency CSA, UL
Voltage - Rated AC 125V
Reference Standard CE; CSA; UL
Current Rating 250mA
Reach Compliance Code not_compliant
Packing Method TAPE AND REEL
Voltage - Rated DC 125V
HTS Code 8536.10.00.40
Terminal Finish Silver (Ag)
Resistance 576.5mOhm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e4
Size / Dimension 0.240Lx0.106W x 0.106 H 6.10mmx2.69mmx2.69mm
Series NANO2? 453
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Terminal Shape WRAPAROUND
Package / Case 2-SMD, Square End Block
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
