0449.750MR
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, Square End Block
Category Circuit Protection / Fuses
Description
Fuse Chip Slow Blow Acting 0.75A 125V SMD Solder Pad 6.1 X 2.69mm Ceramic T/R cULus
PDF
/
Buying Options
Total Price: USD $0.85
Unit Price: USD $0.853328
≥1 USD $0.853328
≥10 USD $0.805028
≥100 USD $0.759461
≥500 USD $0.716469
≥1000 USD $0.675922
Inventory: 1148
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-SMD, Square End Block
Housing Material Ceramic
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series NANO2? 449
Size / Dimension 0.240Lx0.106W x 0.106 H 6.10mmx2.69mmx2.69mm
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Resistance 408mOhm
Terminal Finish Gold (Au)
Voltage - Rated DC 125V
Packing Method TAPE AND REEL
Depth 2.69mm
Current Rating 750mA
Reference Standard CSA; UL
Voltage - Rated AC 125V
Approval Agency cULus
Body Length or Diameter 6.1mm
Physical Dimension 6.1mm x 2.69mm x 2.69mm
Response Time Slow Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 50A
Melting I2t 0.847
DC Cold Resistance 0.408Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Fuse Current 750mA
Trip Time or Delay 14400 s
Pre-arcing Rating 0.84 A2/s
Dimensions
Height 2.6924mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
