0434004.NRP
RoHS
/
Package 0603 (1608 Metric)
Category Circuit Protection / Fuses
Description
Surface Mount Fuses 32V 4A VFA Slimline
PDF
/
Inventory: 3610
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 813μm
Length 1.6002mm
Height 304.8μm
Technical
DC Cold Resistance 0.017Ohms
Melting I2t 0.352
Breaking Capacity @ Rated Voltage 35A
Fuse Type Board Mount (Cartridge Style Excluded)
Response Time Fast Blow
Case Code (Imperial) 0603
Approval Agency CSA, UL
Case Code (Metric) 1608
Voltage - Rated AC 32V
Current Rating 4A
Current Rating (Amps) 4A
Voltage - Rated DC 32V
Composition Thin Film
Min Operating Temperature -55°C
Max Operating Temperature 90°C
Resistance 17mOhm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.063Lx0.032W x 0.012 H 1.60mmx0.81mmx0.31mm
Series 434
Packaging Tape & Reel (TR)
Operating Temperature -55°C~90°C
Physical
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
