043302.5NR
RoHS
/
Package 1206 (3216 Metric)
Category Circuit Protection / Fuses
Description
FUSE BRD MNT 2.5A 32VAC/VDC 1206
PDF
/
Buying Options
Total Price: USD $7
Unit Price: USD $7.00055
≥1 USD $7.00055
≥10 USD $5.7437
≥100 USD $5.56415
≥500 USD $5.3846
≥1000 USD $5.20505
Inventory: 7013
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height 584.2μm
Technical
Blow Characteristic VERY FAST
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.03065Ohm
Melting I2t 0.5
Breaking Capacity @ Rated Voltage 50A
Fuse Type Board Mount (Cartridge Style Excluded)
Response Time Fast Blow
Case Code (Imperial) 1206
Body Length or Diameter 3.18mm
Approval Agency CSA, UL
Case Code (Metric) 3216
Voltage - Rated AC 32V
Reference Standard CSA; UL
Current Rating 2.5A
Reach Compliance Code unknown
Depth 1.52mm
Packing Method TAPE AND REEL
Voltage - Rated DC 32V
HTS Code 8536.10.00.40
Composition Thin Film
Terminal Finish TIN LEAD
Resistance 30.65mOhm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Size / Dimension 0.125Lx0.060W x 0.023 H 3.18mmx1.52mmx0.58mm
Series 433
Packaging Tape & Reel (TR)
Operating Temperature -55°C~90°C
Physical
Terminal Shape WRAPAROUND
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Mount Surface Mount
