0326007.H
RoHS
/
Package 3AB, 3AG, 1/4 x 1-1/4
Category Circuit Protection / Fuses
Description
FUSE CERAMIC 7A 250VAC 3AB 3AG
PDF
/
Inventory: 6211
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Body Height 31.75mm
Diameter 6.35mm
Technical
Trip Time or Delay 14400 s
Joule Integral-Nom 47 J
Fuse Size 3AB
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.0225Ohm
Melting I2t 47.3
Breaking Capacity @ Rated Voltage 400A
Fuse Type Cartridge, Ceramic
Response Time Slow Blow
Physical Dimension 6.35mm x 31.75mm
Approval Agency CSA, UL
Voltage - Rated AC 250V
Reference Standard CE; CSA; KC; PSE; UL
Current Rating 7A
Voltage - Rated DC 250V
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Nickel (Ni)
Resistance 22.5mOhm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.250Diax1.250L 6.35mmx31.75mm
Series 326
Packaging Bulk
Physical
Terminal Shape END CAP
Surface Mount NO
Package / Case 3AB, 3AG, 1/4 x 1-1/4
Mounting Type Holder
