0325020.MXDP

Littelfuse Inc.
RoHS
RoHS RoHS compliant
Package 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Category Circuit Protection / Fuses
Description FUSE CERM 20A 250VAC 60VDC 3AB
PDF
/
Buying Options
Total Price: USD $2.46
Unit Price: USD $2.464
≥1 USD $2.464
≥10 USD $2.34608
≥100 USD $2.22904
≥500 USD $1.799072
≥1000 USD $1.525304
≥3000 USD $1.486214
Inventory: 944
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Technical

Trip Time or Delay 14400 s
Joule Integral-Nom 2507 J
Fuse Size 3AB
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.0042Ohm
Melting I2t 1900
Breaking Capacity @ Rated Voltage 400A AC 500A DC
Fuse Type Cartridge, Ceramic
Response Time Slow Blow
Body Length or Diameter 6.99mm
Approval Agency CE, CSA, UL
Voltage - Rated AC 250V
Reference Standard CE; CSA; UL
Current Rating 20A
Voltage - Rated DC 60V
HTS Code 8536.10.00.40
Terminal Finish Tin (Sn)
Resistance 4.2mOhm
ECCN Code EAR99
Termination Axial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.275Diax1.288L 6.99mmx32.72mm
Series 325
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Housing Material Ceramic
Number of Pins 2
Terminal Shape PIN WIRE
Package / Case 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 11 Weeks
