0325003.H

Littelfuse Inc.
RoHS
/
Package 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Category Circuit Protection / Fuses
Description FUSE CERAMIC 3A 250VAC 3AB 3AG
PDF
/
Inventory: 9220
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Dimensions

Body Height 32.72mm
Diameter 6.99mm

Technical

Trip Time or Delay 14400 s
Joule Integral-Nom 200 J
Fuse Size 3AB
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.06Ohm
Melting I2t 200
Breaking Capacity @ Rated Voltage 100A
Fuse Type Cartridge, Ceramic
Response Time Slow Blow
Operating Temperature (Min) -55°C
Physical Dimension 6.99mm x 32.72mm
Operating Temperature (Max) 125°C
Approval Agency CSA, UL
Voltage - Rated AC 250V
Reference Standard CE; CSA; KC; PSE; UL
Current Rating 3A
Voltage - Rated DC 250V
HTS Code 8536.10.00.40
Terminal Finish Tin (Sn)
Resistance 60mOhm
ECCN Code EAR99
Termination Axial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 0.275Diax1.288L 6.99mmx32.72mm
Series 325
Packaging Bulk

Physical

Terminal Shape PIN WIRE
Package / Case 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Mounting Type Through Hole
Mount Through Hole
