0324003.HXP
RoHS
RoHS compliant
RoHS compliantPackage 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Category Circuit Protection / Fuses
Description
FUSE CERM 3A 250VAC 125VDC 3AB
PDF
/
Buying Options
Total Price: USD $1.72
Unit Price: USD $1.7248
≥1 USD $1.7248
≥10 USD $1.64032
≥100 USD $1.5576
≥500 USD $1.256992
≥1000 USD $1.065768
≥3000 USD $1.038426
Inventory: 107
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Body Height 32.72mm
Diameter 6.99mm
Technical
Fuse Current 3A
Joule Integral-Nom 14 J
Fuse Size 3AB
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.0432Ohm
Melting I2t 14.6
Breaking Capacity @ Rated Voltage 100A AC 10kA DC
Fuse Type Cartridge, Ceramic
Response Time Fast Blow
Physical Dimension 6.99mm x 32.72mm
Approval Agency CE, CSA, K-MARK, PSE, UL
Voltage - Rated AC 250V
Reference Standard CE; CSA; KC; PSE; UL
Current Rating 3A
Reach Compliance Code unknown
Voltage - Rated DC 125V
HTS Code 8536.10.00.40
Terminal Finish Tin (Sn)
Resistance 43.2mOhm
ECCN Code EAR99
Termination Axial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.275Diax1.288L 6.99mmx32.72mm
Series 324
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Ceramic
Terminal Shape PIN WIRE
Package / Case 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 11 Weeks
