0324.375MXP
RoHS
RoHS compliant
RoHS compliantPackage 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Category Circuit Protection / Fuses
Description
FUSE CERAMIC 375MA 250VAC 125VDC
PDF
/
Inventory: 5507
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Body Height 32.72mm
Technical
Fuse Current 375mA
Fuse Size 3AB
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.82Ohm
Melting I2t 0.05
Breaking Capacity @ Rated Voltage 35A AC 10kA DC
Fuse Type Cartridge, Ceramic
Response Time Fast Blow
Power Dissipation 638mW
Physical Dimension 6.99mm x 32.72mm
Body Length or Diameter 6.99mm
Approval Agency CE, CSA, UL
Voltage - Rated AC 250V
Reference Standard CE; CSA; UL
Current Rating 375mA
Voltage - Rated DC 125V
HTS Code 8536.10.00.40
Terminal Finish Tin (Sn)
Resistance 820mOhm
ECCN Code EAR99
Termination Axial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.275Diax1.288L 6.99mmx32.72mm
Series 324
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Ceramic
Terminal Shape PIN WIRE
Package / Case 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 11 Weeks
