0322030.H
RoHS
/
Package 3AB, 3AG, 1/4 x 1-1/4
Category Circuit Protection / Fuses
Description
FUSE CERAMIC 30A 65VAC/VDC 3AB
PDF
/
Inventory: 4410
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Body Height 31.75mm
Diameter 6.35mm
Technical
Pre-arcing Rating 540 A2/s
Trip Time or Delay 14400 s
Joule Integral-Nom 540 J
Fuse Size 3AB
Blow Characteristic VERY FAST
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.0023Ohm
Breaking Capacity @ Rated Voltage 200A
Fuse Type Cartridge, Ceramic
Response Time Fast Blow
Operating Temperature (Min) -55°C
Physical Dimension 6.35mm x 31.75mm
Operating Temperature (Max) 125°C
Approval Agency UL
Voltage - Rated AC 65V
Current Rating 30A
Reach Compliance Code unknown
Voltage - Rated DC 65V
Terminal Finish Nickel (Ni)
Resistance 2.3mOhm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 0.250Diax1.250L 6.35mmx31.75mm
Series 322
Packaging Bulk
Physical
Terminal Shape END CAP
Surface Mount NO
Package / Case 3AB, 3AG, 1/4 x 1-1/4
Mounting Type Holder
