0315030.MXP

Littelfuse Inc.
RoHS
RoHS RoHS compliant
Package 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Category Circuit Protection / Fuses
Description FUSE GLASS 30A 32VAC 3AB 3AG
PDF
/
Inventory: 6985
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Terminal Shape PIN WIRE

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Series 315
Size / Dimension 0.275Diax1.275L 6.99mmx32.39mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Axial
ECCN Code EAR99
Resistance 1.2mOhm
HTS Code 8536.10.00.40
Voltage - Rated DC 32V
Reach Compliance Code unknown
Current Rating 30A
Reference Standard UL
Voltage - Rated AC 32V
Approval Agency UL
Physical Dimension 32.34mm x 6.98mm
Response Time Slow Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 300A
Melting I2t 26900
DC Cold Resistance 0.0012Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Joule Integral-Nom 26900 J

Dimensions

Diameter 6.99mm
Body Height 6.98mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
