0315.750MXP
RoHS
RoHS compliant
RoHS compliantPackage 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Category Circuit Protection / Fuses
Description
FUSE GLASS 750MA 250VAC 3AB 3AG
PDF
/
Inventory: 9068
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Body Height 6.98mm
Diameter 6.99mm
Technical
Joule Integral-Nom 7 J
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.6215Ohm
Melting I2t 7.16
Breaking Capacity @ Rated Voltage 35A
Fuse Type Cartridge, Glass
Response Time Slow Blow
Physical Dimension 32.34mm x 6.98mm
Approval Agency CE, CSA, UL
Voltage - Rated AC 250V
Reference Standard CE; CSA; UL
Current Rating 750mA
Reach Compliance Code unknown
Voltage - Rated DC 250V
HTS Code 8536.10.00.40
Resistance 621.5mOhm
ECCN Code EAR99
Termination Axial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.275Diax1.275L 6.99mmx32.39mm
Series 315
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Glass
Terminal Shape PIN WIRE
Package / Case 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 11 Weeks
