0315.200HXP
RoHS
RoHS compliant
RoHS compliantPackage 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Category Circuit Protection / Fuses
Description
FUSE GLASS 200MA 250VAC 3AB 3AG
PDF
/
Inventory: 3552
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Body Height 32.39mm
Diameter 6.99mm
Technical
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 6.59Ohm
Melting I2t 0.27
Breaking Capacity @ Rated Voltage 35A
Fuse Type Cartridge, Glass
Response Time Slow Blow
Physical Dimension 6.99mm x 32.39mm
Approval Agency CE, CSA, UL
Voltage - Rated AC 250V
Reference Standard CE; CSA; UL
Current Rating 200mA
Reach Compliance Code unknown
Voltage - Rated DC 250V
HTS Code 8536.10.00.40
Terminal Finish Matte Tin (Sn)
Resistance 6.59Ohm
ECCN Code EAR99
Termination Axial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.275Diax1.275L 6.99mmx32.39mm
Series 315
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Terminal Shape PIN WIRE
Package / Case 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 11 Weeks
