0314015.MXP
RoHS
RoHS compliant
RoHS compliantPackage 3AB, 3AG, 1/4 x 1-1/4
Category Circuit Protection / Fuses
Description
Fuse Miniature Fast Acting 15A 280V Holder Cartridge 6.3 X 32mm Ceramic Bulk CE/CSA/PSE/UL
PDF
/
Buying Options
Total Price: USD $0.23
Unit Price: USD $0.2299
≥1 USD $0.2299
≥10 USD $0.18905
≥100 USD $0.1824
≥500 USD $0.1767
≥1000 USD $0.171
Inventory: 1099
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Body Height 31.75mm
Diameter 6.35mm
Technical
Fuse Current 15A
Joule Integral-Nom 292 J
Fuse Size 3AB
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.00505Ohm
Melting I2t 292
Breaking Capacity @ Rated Voltage 750A AC 10kA DC
Fuse Type Cartridge, Ceramic
Response Time Fast Blow
Working Voltage 250V
Physical Dimension 6.35mm x 31.75mm
Approval Agency CE, CSA, K-MARK, UL
Voltage - Rated AC 250V
Reference Standard CE; CSA; KC; PSE; UL
Current Rating 15A
Voltage - Rated DC 125V
Resistance 5.05mOhm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.250Diax1.250L 6.35mmx31.75mm
Series 314
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Ceramic
Number of Pins 2
Terminal Shape END CAP
Package / Case 3AB, 3AG, 1/4 x 1-1/4
Mounting Type Holder
Mount Holder, Surface Mount
Contact Plating Nickel
Contact Material Brass
Supply Chain
Factory Lead Time 11 Weeks
