03132.25HXP
RoHS
RoHS compliant
RoHS compliantPackage 3AB, 3AG, 1/4 x 1-1/4
Category Circuit Protection / Fuses
Description
Fuse Miniature Slow Blow Acting 2.25A 250V Holder Cartridge 6.3 X 32mm Glass Bulk CE/CSA/PSE/UL
PDF
/
Buying Options
Total Price: USD $0.78
Unit Price: USD $0.7832
≥1 USD $0.7832
≥10 USD $0.76208
≥100 USD $0.7128
≥500 USD $0.5896
≥1000 USD $0.491304
≥3000 USD $0.479072
Inventory: 1184
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Holder
Package / Case 3AB, 3AG, 1/4 x 1-1/4
Surface Mount NO
Terminal Shape END CAP
Housing Material Glass
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series 313
Size / Dimension 0.250Diax1.250L 6.35mmx31.75mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Clip
ECCN Code EAR99
Resistance 96mOhm
Terminal Finish Tin (Sn)
Voltage - Rated DC 250V
Current Rating 2.25A
Reference Standard CE; CSA; KTL; PSE; UL
Voltage - Rated AC 250V
Approval Agency CE, CSA, K-MARK, PSE, UL
Physical Dimension 6.35mm x 31.75mm
Working Voltage 250V
Response Time Slow Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 100A
Melting I2t 121
DC Cold Resistance 0.0968Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Fuse Size 3AG
Joule Integral-Nom 121 J
Fuse Current 2.25A
Trip Time or Delay 14400 s
Fuse Class Supplemental
Dimensions
Diameter 6.35mm
Body Height 31.75mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
