0313030.MXP

Littelfuse Inc.
RoHS
RoHS RoHS compliant
Package 3AB, 3AG, 1/4 x 1-1/4
Category Circuit Protection / Fuses
Description FUSE GLASS 30A 32VAC 3AB 3AG
PDF
/
Buying Options
Total Price: USD $1.39
Unit Price: USD $1.3904
≥1 USD $1.3904
≥10 USD $1.32176
≥100 USD $1.25576
≥500 USD $1.013408
≥1000 USD $0.859144
≥3000 USD $0.837126
Inventory: 507
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Diameter 6.35mm

Technical

Fuse Class Supplemental
Trip Time or Delay 14400 s
Fuse Current 30A
Joule Integral-Nom 26900 J
Outside Diameter 6.35 mm
Fuse Size 3AG
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.0012Ohm
Melting I2t 26900
Breaking Capacity @ Rated Voltage 300A
Fuse Type Cartridge, Glass
Response Time Slow Blow
Physical Dimension 31.75mm x 6.35mm
Approval Agency UL
Voltage - Rated AC 32V
Reference Standard UL
Current Rating 30A
Voltage - Rated DC 32V
Terminal Finish Tin (Sn)
Resistance 1.2mOhm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.250Diax1.250L 6.35mmx31.75mm
Series 313
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Housing Material Glass
Terminal Shape END CAP
Surface Mount NO
Package / Case 3AB, 3AG, 1/4 x 1-1/4
Mounting Type Holder
Contact Plating Nickel
Contact Material Brass

Supply Chain

Factory Lead Time 13 Weeks
