0313.800VXP
RoHS
RoHS compliant
RoHS compliantPackage 3AB, 3AG, 1/4 x 1-1/4
Category Circuit Protection / Fuses
Description
Cartridge Fuses 250V SB 3AG 0.8AMP
PDF
/
Inventory: 5708
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Holder
Package / Case 3AB, 3AG, 1/4 x 1-1/4
Surface Mount NO
Terminal Shape END CAP
Weight 2.799997g
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series 313
Size / Dimension 0.250Diax1.250L 6.35mmx31.75mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Resistance 554mOhm
Terminal Finish Tin (Sn)
Current Rating 800mA
Reference Standard CE; CSA; UL
Voltage - Rated AC 250V
Approval Agency CE, CSA, UL
Body Length or Diameter 6.35mm
Physical Dimension 6.35mm x 31.75mm
Response Time Slow Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 35A
Melting I2t 8
DC Cold Resistance 0.554Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Joule Integral-Nom 8 J
Dimensions
Body Height 31.75mm
Compliance
RoHS Status ROHS3 Compliant
