0312020.H
RoHS
/
Package 3AB, 3AG, 1/4 x 1-1/4
Category Circuit Protection / Fuses
Description
FUSE GLASS 20A 32VAC 3AB 3AG
PDF
/
Inventory: 8116
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Holder
Package / Case 3AB, 3AG, 1/4 x 1-1/4
Surface Mount NO
Terminal Shape END CAP
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series 312
Size / Dimension 0.250Diax1.250L 6.35mmx31.75mm
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Clip
ECCN Code EAR99
Resistance 3.4mOhm
Terminal Finish Tin (Sn)
Voltage - Rated DC 32V
Current Rating 20A
Reference Standard CSA; UL
Voltage - Rated AC 32V
Approval Agency CSA, UL
Physical Dimension 6.35mm x 31.75mm
Response Time Fast Blow
Fuse Type Cartridge, Glass
DC Cold Resistance 0.0034Ohm
Circuit Protection Type ELECTRIC FUSE
Joule Integral-Nom 1029 J
Rated Breaking Capacity 300 A
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Body Height 31.75mm
Diameter 6.35mm
