0312.250H

Littelfuse Inc.
RoHS
/
Package 3AB, 3AG, 1/4 x 1-1/4
Category Circuit Protection / Fuses
Description FUSE GLASS 250MA 250VAC 3AB 3AG
PDF
/
Inventory: 933
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Holder
Package / Case 3AB, 3AG, 1/4 x 1-1/4
Surface Mount NO
Terminal Shape END CAP

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Series 312
Size / Dimension 0.250Diax1.250L 6.35mmx31.75mm
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Clip
ECCN Code EAR99
Resistance 2Ohm
Terminal Finish Tin (Sn)
Voltage - Rated DC 250V
Current Rating 250mA
Reference Standard CE; CSA; UL
Voltage - Rated AC 250V
Approval Agency CSA, UL
Physical Dimension 6.35mm x 31.75mm
Response Time Fast Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 35A
Melting I2t 0.0355
DC Cold Resistance 2Ohm
Circuit Protection Type ELECTRIC FUSE
Trip Time or Delay 14400 s
Pre-arcing Rating 0.035 A2/s

Dimensions

Diameter 6.35mm
Body Height 31.75mm

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
