0297005.WXUL
RoHS
RoHS compliant
RoHS compliantPackage Blade, Miniature
Category Circuit Protection / Fuses
Description
FUSE AUTO 5A 32VDC BLADE MINI
PDF
/
Buying Options
Total Price: USD $0.66
Unit Price: USD $0.663015
≥1 USD $0.663015
≥200 USD $0.265206
≥500 USD $0.256016
≥1000 USD $0.252077
Inventory: 5404
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.8mm
Length 10.9mm
Height 8.7884mm
Technical
DC Cold Resistance 0.01775Ohms
Melting I2t 25
Breaking Capacity @ Rated Voltage 1kA
Fuse Type Automotive
Response Time Fast Blow
Approval Agency SAE, UL
Current Rating 5A
Current Rating (Amps) 5A
Voltage - Rated DC 32V
Color Tan
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 17.75mOhm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.429Lx0.150W x 0.346 H 10.90mmx3.80mmx8.80mm
Series MINI? 297
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Package / Case Blade, Miniature
Mounting Type Holder
Mount Holder
