028502.5MXP
RoHS
RoHS compliant
RoHS compliantPackage 5mm x 20mm
Category Circuit Protection / Fuses
Description
FUSE CERAMIC 2.5A 250VAC 5X20MM
PDF
/
Inventory: 2456
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Body Height 20mm
Technical
Joule Integral-Nom 25 J
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.0384Ohm
Melting I2t 25.625
Breaking Capacity @ Rated Voltage 1.5kA
Fuse Type Cartridge, Ceramic
Response Time Slow Blow
Physical Dimension 5.2mm x 20mm
Body Length or Diameter 5.2mm
Approval Agency PSE
Voltage - Rated AC 250V
Current Rating 2.5A
Reach Compliance Code unknown
Terminal Finish Gold (Au)
Resistance 38.4mOhm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
Series 285
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Terminal Shape END CAP
Surface Mount NO
Package / Case 5mm x 20mm
Mounting Type Holder
Supply Chain
Factory Lead Time 15 Weeks
