0263.250M
RoHS
/
Package Axial
Category Circuit Protection / Fuses
Description
FUSE BRD MNT 250MA 250VAC AXIAL
PDF
/
Inventory: 4702
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Axial
Surface Mount NO
Terminal Shape PIN WIRE
Technical
Operating Temperature -55°C~125°C
Series PICO? II 263
Size / Dimension 0.155Diax0.280L 3.94mmx7.11mm
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8536.10.00.40
Current Rating (Amps) 250mA
Packing Method AMMO PACK
Reach Compliance Code unknown
Reference Standard CSA; UL
Voltage - Rated AC 250V
Approval Agency CSA, UR
Body Length or Diameter 3.94mm
Physical Dimension 3.94mm x 7.11mm
Response Time Fast Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 50A
Rated Current 0.25A
Melting I2t 0.0165
DC Cold Resistance 0.715Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic VERY FAST
Trip Time or Delay 14400 s
Dimensions
Body Height 7.11mm
Compliance
RoHS Status Non-RoHS Compliant
