0253015.M
RoHS
/
Package Axial
Category Circuit Protection / Fuses
Description
Axial PICO? II 253 Through Hole CSA QPL UR Board Mount (Cartridge Style Excluded) Fuse 50A AC 300A DC 15A 2.41mm 68J
PDF
/
Buying Options
Total Price: USD $9.73
Unit Price: USD $9.7328
≥1 USD $9.7328
≥10 USD $9.38256
≥100 USD $9.03584
≥500 USD $6.950416
≥1000 USD $5.90788
≥3000 USD $5.560368
Inventory: 95
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Terminal Shape PIN WIRE
Housing Material Ceramic
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series PICO? II 253
Size / Dimension 0.103Diax0.280L 2.61mmx7.11mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Resistance 4.46mOhm
Terminal Finish Pure Tin (Sn)
Additional Feature RATED BREAKING CAPACITY AT 125 VDC: 300 A, PRE ARCHING TIME: OPEN WITHIN 10000 MILLISEC AT 200% RATED CURRENT
HTS Code 8536.10.00.40
Voltage - Rated DC 32V
Packing Method TAPE AND REEL
Reach Compliance Code unknown
Current Rating 1.5A
Reference Standard CSA; QPL; UL
Voltage - Rated AC 32V
Approval Agency CSA, QPL, UR
Physical Dimension 2.61mm x 7.11mm
Current 15A
Response Time Fast Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 50A AC 300A DC
Melting I2t 68.8
DC Cold Resistance 0.00446Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic VERY FAST
Joule Integral-Nom 68 J
Dimensions
Diameter 2.41mm
Body Height 7.11mm
Compliance
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
