0251.375PF001L
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Circuit Protection / Fuses
Description
FUSE BOARD MNT 375MA 125VAC/VDC
PDF
/
Inventory: 3100
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series PICO? II 251
Size / Dimension 0.110Diax0.280L 2.80mmx7.11mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Axial
Resistance 395mOhm
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Voltage - Rated DC 125V
Current Rating (Amps) 375mA
Current Rating 375mA
Voltage - Rated AC 125V
Approval Agency CSA, cURus
Response Time Fast Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 50A AC 300A DC
Melting I2t 0.0296
DC Cold Resistance 0.395Ohms
Dimensions
Length 7.112mm
Compliance
RoHS Status ROHS3 Compliant
