023902.5MXP

Littelfuse Inc.
RoHS
RoHS RoHS compliant
Package 5mm x 20mm
Category Circuit Protection / Fuses
Description LITTELFUSE 023902.5MXP Cartridge Fuse, 239 Series, 2.5 A, 250 V, 5mm x 20mm, 100 A
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.9152
≥1 USD $0.9152
≥10 USD $0.88352
≥100 USD $0.8272
≥500 USD $0.684464
≥1000 USD $0.570328
≥3000 USD $0.556054
Inventory: 1194
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Body Height 20mm
Diameter 5.2mm

Technical

Fuse Class Supplemental
Trip Time or Delay 14400 s
Fuse Current 2.5A
Joule Integral-Nom 79 J
Outside Diameter 5.2 mm
Fuse Size 5x20mm
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.0583Ohm
Melting I2t 79.705
Breaking Capacity @ Rated Voltage 100A
Fuse Type Cartridge, Glass
Response Time Slow Blow
Current 2.5A
Physical Dimension 5.2mm x 20mm
Approval Agency CE, CSA, KC, PSE, UL
Voltage - Rated AC 250V
Reference Standard CE; CSA; KC; PSE; UL
Current Rating 2.5A
Voltage - Rated DC 250V
Terminal Finish Nickel (Ni)
Resistance 58.3mOhm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
Series 239
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Housing Material Glass
Terminal Shape END CAP
Surface Mount NO
Package / Case 5mm x 20mm
Mounting Type Holder

Supply Chain

Factory Lead Time 15 Weeks
