0239.800MXP
RoHS
RoHS compliant
RoHS compliantPackage 5mm x 20mm
Category Circuit Protection / Fuses
Description
LITTELFUSE 0239.800MXP Cartridge Fuse, 239 Series, 800 mA, 250 V, 5mm x 20mm, 35 A
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.9152
≥1 USD $0.9152
≥10 USD $0.88352
≥100 USD $0.8272
≥500 USD $0.684464
≥1000 USD $0.570328
≥3000 USD $0.556054
Inventory: 77
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Diameter 5.2mm
Technical
Fuse Class Supplemental
Trip Time or Delay 14400 s
Fuse Current 800mA
Joule Integral-Nom 7 J
Outside Diameter 5.2 mm
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.4155Ohm
Melting I2t 7.565
Breaking Capacity @ Rated Voltage 35A
Fuse Type Cartridge, Glass
Response Time Slow Blow
Current 800mA
Working Voltage 250V
Approval Agency CE, CSA, KC, UL
Voltage - Rated AC 250V
Reference Standard CE; CSA; KC; UL
Current Rating 800mA
Voltage - Rated DC 250V
Terminal Finish Nickel (Ni)
Resistance 415.5mOhm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
Series 239
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Glass
Number of Pins 2
Terminal Shape END CAP
Surface Mount NO
Package / Case 5mm x 20mm
Mounting Type Holder
Supply Chain
Factory Lead Time 15 Weeks
