0239.400HXEP
RoHS
RoHS compliant
RoHS compliantPackage 5mm x 20mm (Axial)
Category Circuit Protection / Fuses
Description
FUSE GLASS 400MA 250VAC 5X20MM
PDF
/
Inventory: 3830
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 5mm x 20mm (Axial)
Terminal Shape PIN WIRE
Housing Material Glass
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series 239
Size / Dimension 0.217Diax0.846L 5.50mmx21.50mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Axial
ECCN Code EAR99
Resistance 1.475Ohm
Terminal Finish Tin (Sn)
HTS Code 8536.10.00.40
Voltage - Rated DC 250V
Reach Compliance Code unknown
Current Rating 400mA
Reference Standard CE; CSA; KC; UL
Voltage - Rated AC 250V
Approval Agency CE, CSA, KC, UL
Physical Dimension 5.8mm x 22.5mm
Response Time Slow Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 35A
Melting I2t 1.49
DC Cold Resistance 1.475Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Fuse Size 5x20mm
Joule Integral-Nom 1 J
Trip Time or Delay 14400 s
Fuse Class Supplemental
Pre-arcing Rating 1.4 A2/s
Dimensions
Diameter 5.8mm
Body Height 22.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
