0232010.MX125P
RoHS
RoHS compliant
RoHS compliantPackage 5mm x 20mm
Category Circuit Protection / Fuses
Description
FUSE GLASS 10A 125VAC 5X20MM
PDF
/
Buying Options
Total Price: USD $0.88
Unit Price: USD $0.88
≥1 USD $0.88
≥10 USD $0.85008
≥100 USD $0.79552
≥500 USD $0.65824
≥1000 USD $0.548592
≥3000 USD $0.534829
Inventory: 965
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mounting Type Holder
Package / Case 5mm x 20mm
Housing Material Glass
Terminal Shape END CAP
Surface Mount NO
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Body Height 20mm
Diameter 5mm
Technical
Joule Integral-Nom 290 J
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.0059Ohm
Melting I2t 290.665
Breaking Capacity @ Rated Voltage 300A
Fuse Type Cartridge, Glass
Response Time Medium Blow
Physical Dimension 5.2mm x 20mm
Approval Agency CE, KC, PSE
Voltage - Rated AC 125V
Reference Standard CE; KC; PSE
Current Rating 10A
Terminal Finish Nickel (Ni)
Resistance 5.9mOhm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
Series 232
Packaging Bulk
Operating Temperature -55°C~125°C
