0230001.DRT3P

Littelfuse Inc.
RoHS
RoHS RoHS compliant
Package Cartridge, Non-Standard (Axial)
Category Circuit Protection / Fuses
Description FUSE GLASS 1A 250VAC/125VDC AXL
PDF
/
Inventory: 9689
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Body Height 14.48mm
Diameter 4.7mm

Technical

Joule Integral-Nom 5 J
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.212Ohm
Melting I2t 5.64
Breaking Capacity @ Rated Voltage 35A AC 10kA DC
Fuse Type Cartridge, Glass
Response Time Slow Blow
Physical Dimension 4.7mm x 14.48mm
Approval Agency CE, CSA, PSE, UL
Voltage - Rated AC 250V
Reference Standard CE; CSA; PSE; UL
Current Rating 1A
Reach Compliance Code unknown
Packing Method TAPE AND REEL
Voltage - Rated DC 125V
HTS Code 8536.10.00.40
Terminal Finish Matte Tin (Sn)
Resistance 212mOhm
ECCN Code EAR99
Termination Axial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.177Diax0.571L 4.50mmx14.50mm
Series 230
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Housing Material Glass
Terminal Shape PIN WIRE
Package / Case Cartridge, Non-Standard (Axial)
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 15 Weeks
