02292.25HXSP
RoHS
RoHS compliant
RoHS compliantPackage 2AG, 5mm x 15mm
Category Circuit Protection / Fuses
Description
FUSE GLASS 2.25A 250VAC 125VDC
PDF
/
Inventory: 3871
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Holder
Package / Case 2AG, 5mm x 15mm
Surface Mount NO
Terminal Shape END CAP
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series 229
Size / Dimension 0.177Diax0.570L 4.50mmx14.48mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Clip
ECCN Code EAR99
Resistance 56.2mOhm
Terminal Finish Matte Tin (Sn)
Voltage - Rated DC 125V
Reach Compliance Code unknown
Current Rating 2.25A
Reference Standard CE; CSA; PSE; UL
Voltage - Rated AC 250V
Approval Agency CE, CSA, PSE, UL
Physical Dimension 4.5mm x 14.48mm
Response Time Slow Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 35A AC 10kA DC
Melting I2t 39
DC Cold Resistance 0.0567Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Joule Integral-Nom 39 J
Dimensions
Diameter 4.5mm
Body Height 14.48mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
