02291.25MXP
RoHS
RoHS compliant
RoHS compliantPackage 2AG, 5mm x 15mm
Category Circuit Protection / Fuses
Description
FUSE GLASS 1.25A 250VAC 125VDC
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.528
≥1 USD $0.528
≥10 USD $0.50688
≥100 USD $0.4752
≥500 USD $0.393008
≥1000 USD $0.327536
≥3000 USD $0.319334
Inventory: 922
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Holder
Package / Case 2AG, 5mm x 15mm
Surface Mount NO
Terminal Shape END CAP
Housing Material Glass
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series 229
Size / Dimension 0.177Diax0.570L 4.50mmx14.48mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Clip
ECCN Code EAR99
Resistance 145mOhm
Terminal Finish Tin (Sn)
Voltage - Rated DC 125V
Current Rating 1.25A
Reference Standard CSA; CE; PSE; UL
Voltage - Rated AC 250V
Approval Agency CE, CSA, PSE, UL
Physical Dimension 4.5mm x 14.48mm
Power Dissipation 377mW
Response Time Slow Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 35A AC 10kA DC
Melting I2t 9.8
DC Cold Resistance 0.146Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Outside Diameter 4.5 mm
Joule Integral-Nom 9 J
Fuse Current 1.25A
Built-in Feature INDICATOR
Dimensions
Diameter 4.5mm
Body Height 14.48mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
