022903.5MXP
RoHS
RoHS compliant
RoHS compliantPackage 2AG, 5mm x 15mm
Category Circuit Protection / Fuses
Description
FUSE GLASS 3.5A 250VAC 125VDC
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.528
≥1 USD $0.528
≥10 USD $0.50688
≥100 USD $0.4752
≥500 USD $0.393008
≥1000 USD $0.327536
≥3000 USD $0.319334
Inventory: 832
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Holder
Package / Case 2AG, 5mm x 15mm
Surface Mount NO
Terminal Shape END CAP
Housing Material Glass
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series 229
Size / Dimension 0.177Diax0.570L 4.50mmx14.48mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Clip
ECCN Code EAR99
Resistance 31mOhm
Terminal Finish Tin (Sn)
Voltage - Rated DC 125V
Current Rating 3.5A
Reference Standard CSA; CE; PSE; UL
Voltage - Rated AC 250V
Approval Agency CE, CSA, PSE, UL
Physical Dimension 4.5mm x 14.48mm
Power Dissipation 481mW
Response Time Slow Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 100A AC 10kA DC
Melting I2t 110
DC Cold Resistance 0.0312Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Fuse Size 2AG
Outside Diameter 4.5 mm
Joule Integral-Nom 110 J
Fuse Current 3.5A
Trip Time or Delay 14400 s
Built-in Feature INDICATOR
Dimensions
Diameter 4.5mm
Body Height 14.48mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
