0229004.VXP
RoHS
RoHS compliant
RoHS compliantPackage 2AG, 5mm x 15mm
Category Circuit Protection / Fuses
Description
FUSE GLASS 4A 125VAC/VDC 2AG
PDF
/
Buying Options
Total Price: USD $7.83
Unit Price: USD $7.834074
≥1 USD $7.834074
≥200 USD $3.126015
≥500 USD $3.022296
≥1000 USD $2.96978
Inventory: 3511
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Holder
Package / Case 2AG, 5mm x 15mm
Surface Mount NO
Terminal Shape END CAP
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series 229
Size / Dimension 0.177Diax0.570L 4.50mmx14.48mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Resistance 25.8mOhm
Terminal Finish Matte Tin (Sn)
Voltage - Rated DC 125V
Reach Compliance Code unknown
Current Rating 4A
Reference Standard CE; CSA; PSE; UL
Voltage - Rated AC 125V
Approval Agency CE, CSA, PSE, UL
Body Length or Diameter 4.5mm
Physical Dimension 4.5mm x 14.48mm
Response Time Slow Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 400A
Melting I2t 148
DC Cold Resistance 0.0258Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Joule Integral-Nom 148 J
Built-in Feature INDICATOR
Dimensions
Body Height 14.48mm
Compliance
RoHS Status ROHS3 Compliant
