0225.500MXP
RoHS
RoHS compliant
RoHS compliantPackage 2AG, 5mm x 15mm
Category Circuit Protection / Fuses
Description
Fuse Subminiature Fast Acting 0.5A 250V Holder Cartridge 5 X 15mm Glass Bulk
PDF
/
Buying Options
Total Price: USD $0.61
Unit Price: USD $0.6072
≥1 USD $0.6072
≥10 USD $0.5896
≥100 USD $0.57112
≥500 USD $0.480304
≥1000 USD $0.398728
≥3000 USD $0.362454
Inventory: 1206
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Body Height 14.48mm
Diameter 4.5mm
Technical
Trip Time or Delay 14400 s
Fuse Size 2AG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.265Ohm
Melting I2t 0.365
Breaking Capacity @ Rated Voltage 35A AC 10kA DC
Fuse Type Cartridge, Glass
Response Time Fast Blow
Power Dissipation 35W
Current 500mA
Physical Dimension 4.5mm x 14.48mm
Approval Agency CE, CSA, UL
Voltage - Rated AC 250V
Reference Standard CE; CSA; UL
Current Rating 500mA
Voltage - Rated DC 125V
Terminal Finish Tin (Sn)
Resistance 265mOhm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.177Diax0.570L 4.50mmx14.48mm
Series 225
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Glass
Number of Pins 2
Terminal Shape END CAP
Package / Case 2AG, 5mm x 15mm
Mounting Type Holder
Mount Holder, Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
