0224001.VXP
RoHS
RoHS compliant
RoHS compliantPackage 2AG, 5mm x 15mm (Axial)
Category Circuit Protection / Fuses
Description
FUSE GLASS 1A 250VAC 125VDC 2AG
PDF
/
Buying Options
Total Price: USD $9.7
Unit Price: USD $9.699705
≥1 USD $9.699705
≥200 USD $3.753581
≥500 USD $3.622291
≥1000 USD $3.556646
Inventory: 5733
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 14.478mm
Technical
DC Cold Resistance 0.1027Ohms
Melting I2t 2.22
Breaking Capacity @ Rated Voltage 35A AC 10kA DC
Fuse Type Cartridge, Glass
Response Time Fast Blow
Approval Agency CE, CSA, PSE, UL
Voltage - Rated AC 250V
Current Rating 1A
Current Rating (Amps) 1A
Voltage - Rated DC 125V
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Resistance 102.7mOhm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.185Diax0.570L 4.70mmx14.48mm
Series 224
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case 2AG, 5mm x 15mm (Axial)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 15 Weeks
