0218.040TXP
RoHS
RoHS compliant
RoHS compliantPackage 5mm x 20mm
Category Circuit Protection / Fuses
Description
FUSE GLASS 40MA 250VAC 5X20MM
PDF
/
Buying Options
Total Price: USD $14.09
Unit Price: USD $14.08873
≥1 USD $14.08873
≥200 USD $5.452474
≥500 USD $5.26079
≥1000 USD $5.166262
Inventory: 9178
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mounting Type Holder
Package / Case 5mm x 20mm
Surface Mount NO
Terminal Shape END CAP
Housing Material Glass
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series 218
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Clip
Resistance 31.862Ohm
Additional Feature PRE ARCING TIME: OPEN WITHIN 10 MILLISEC AT 1000% RATED CURRENT
Reach Compliance Code unknown
Current Rating 40mA
Reference Standard CCC; CE; CSA; IEC; KC; SEMKO; UL; VDE
Voltage - Rated AC 250V
Approval Agency CCC, CE, CSA, KC, SEMKO, UL, VDE
Physical Dimension 5.2mm x 20mm
Power Dissipation 1.6W
Response Time Slow Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 35A
Melting I2t 0.011
DC Cold Resistance 31.862Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Dimensions
Diameter 5mm
Body Height 20mm
Compliance
RoHS Status ROHS3 Compliant
