02153.15TXP
RoHS
RoHS compliant
RoHS compliantPackage 5mm x 20mm
Category Circuit Protection / Fuses
Description
Fuse Miniature Slow Blow Acting 3.15A 250V Holder Cartridge 5 X 20mm Ceramic T/R
PDF
/
Inventory: 1769
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Length 20mm
Diameter 5mm
Technical
Fuse Current 3.15A
Outside Diameter 5.2 mm
DC Cold Resistance 0.0283Ohms
Melting I2t 43.255
Breaking Capacity @ Rated Voltage 1.5kA
Fuse Type Cartridge, Ceramic
Response Time Slow Blow
Approval Agency CCC, CE, CSA, KC, PSE, SEMKO, UL, VDE
Voltage - Rated AC 250V
Current Rating 315mA
Current Rating (Amps) 3.15A
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Resistance 28.3mOhm
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
Series 215
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Ceramic
Number of Pins 2
Package / Case 5mm x 20mm
Mounting Type Holder
Mount Holder, Through Hole
Supply Chain
Factory Lead Time 15 Weeks
