0215010.MRET1P
RoHS
RoHS compliant
RoHS compliantPackage 5mm x 20mm (Axial)
Category Circuit Protection / Fuses
Description
FUSE CERAMIC 10A 250VAC 5X20MM
PDF
/
Buying Options
Total Price: USD $2.52
Unit Price: USD $2.5168
≥1 USD $2.5168
≥10 USD $2.40064
≥100 USD $2.28008
≥500 USD $1.84008
≥1000 USD $1.559976
≥3000 USD $1.520006
Inventory: 983
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 5mm x 20mm (Axial)
Terminal Shape PIN WIRE
Housing Material Ceramic
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 215
Size / Dimension 0.228Diax0.886L 5.80mmx22.50mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Clip
Resistance 6.6mOhm
Terminal Finish Tin (Sn)
Voltage - Rated DC 250V
Packing Method TAPE AND REEL
Current Rating 10A
Reference Standard BSI, CE, CSA, PSE, UL, VDE
Voltage - Rated AC 250V
Approval Agency CE, CSA, KC, PSE, SEMKO, UL, VDE
Body Length or Diameter 5.8mm
Physical Dimension 5.8mm x 22.5mm
Power Dissipation 4W
Response Time Slow Blow
Fuse Type Cartridge, Ceramic
Breaking Capacity @ Rated Voltage 1.5kA
Melting I2t 333.565
DC Cold Resistance 0.0066Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Fuse Size 5x20mm
Pre-arcing Rating 333.56 A2/s
Dimensions
Body Height 22.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
