0215005.H
RoHS
/
Package 5mm x 20mm
Category Circuit Protection / Fuses
Description
FUSE CERAMIC 5A 250VAC 5X20MM
PDF
/
Inventory: 1508
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Body Height 20mm
Technical
Pre-arcing Rating 66.09 A2/s
Fuse Class Supplemental
Joule Integral-Nom 66 J
Fuse Size 5x20mm
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.0125Ohm
Melting I2t 82.85
Breaking Capacity @ Rated Voltage 1.5kA
Fuse Type Cartridge, Ceramic
Response Time Slow Blow
Physical Dimension 5.2mm x 20mm
Body Length or Diameter 5.2mm
Approval Agency BSI, CSA, K-MARK, METI, SEMKO, UL
Voltage - Rated AC 250V
Reference Standard CCC; CE; CSA; IEC; KC; PSE; SEMKO; SEV; UL; VDE
Current Rating 5A
Terminal Finish Nickel (Ni)
Resistance 12.5mOhm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
Series 215
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Ceramic
Terminal Shape END CAP
Surface Mount NO
Package / Case 5mm x 20mm
Mounting Type Holder
