015701.5DRT

Littelfuse Inc.
RoHS
RoHS RoHS compliant
Package 2-SMD, Square End Block with Clip
Category Circuit Protection / Fuses
Description FUSE BRD MNT 1.5A 125VAC/VDC SMD
PDF
/
Buying Options
Total Price: USD $3.2
Unit Price: USD $3.2032
≥1 USD $3.2032
≥10 USD $3.09408
≥100 USD $2.98672
≥500 USD $2.346608
≥1000 USD $1.919984
≥3000 USD $1.866621
Inventory: 1084
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Mount Holder, Surface Mount
Mounting Type Holder, Surface Mount
Package / Case 2-SMD, Square End Block with Clip
Terminal Shape WRAPAROUND
Body Material Ceramic

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series NANO2? 157T
Size / Dimension 0.256Lx0.146W x 0.154 H 6.50mmx3.70mmx3.90mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 93.4mOhm
HTS Code 8536.10.00.40
Voltage - Rated DC 125V
Packing Method TAPE AND REEL
Depth 3.7mm
Current Rating 1.5A
Reference Standard PSE; UL
Voltage - Rated AC 125V
Approval Agency cULus, PSE
Body Length or Diameter 6.1mm
Body Breadth 2.69 mm
Physical Dimension 6.1mm x 2.69mm x 2.69mm
Response Time Slow Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 50A
Melting I2t 3.65
DC Cold Resistance 0.0934Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Joule Integral-Nom 3 J
Fuse Current 1.5A

Dimensions

Height 3.9116mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
