0154007.DRL
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, Square End Block with Holder
Category Circuit Protection / Fuses
Description
FUSE BRD MNT 7A 125VAC/VDC 2SMD
PDF
/
Buying Options
Total Price: USD $2.91
Unit Price: USD $2.9128
≥1 USD $2.9128
≥10 USD $2.81776
≥100 USD $2.72008
≥500 USD $2.137344
≥1000 USD $1.748824
≥3000 USD $1.700195
Inventory: 945
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 3.81mm
Technical
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.009Ohm
Melting I2t 10.32
Breaking Capacity @ Rated Voltage 50A
Fuse Type Board Mount (Cartridge Style Excluded)
Response Time Fast Blow
Power Dissipation 125W
Working Voltage 125V
Physical Dimension 9.73mm x 5.03mm x 3.81mm
Body Length or Diameter 9.73mm
Approval Agency PSE, UL
Voltage - Rated AC 125V
Reference Standard CSA; PSE; UL
Current Rating 7A
Reach Compliance Code not_compliant
Depth 5.03mm
Packing Method TAPE AND REEL
Voltage - Rated DC 125V
HTS Code 8536.10.00.40
Resistance 9mOhm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.383Lx0.198W x 0.150 H 9.73mmx5.03mmx3.81mm
Series OMNI-BLOK? 154L
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Terminal Shape WRAPAROUND
Package / Case 2-SMD, Square End Block with Holder
Mounting Type Holder, Surface Mount
Mount Holder, Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
