0154003.DR
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, Square End Block with Holder
Category Circuit Protection / Fuses
Description
FUSE BOARD MNT 3A 125VAC/VDC SMD
PDF
/
Buying Options
Total Price: USD $1.52
Unit Price: USD $1.52308
≥1 USD $1.52308
≥10 USD $1.436868
≥100 USD $1.355531
≥500 USD $1.278812
≥1000 USD $1.206424
Inventory: 1126
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Holder, Surface Mount
Mounting Type Holder, Surface Mount
Package / Case 2-SMD, Square End Block with Holder
Terminal Shape WRAPAROUND
Number of Pins 2
Body Material Thermoplastic
Terminal Material Copper
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series OMNI-BLOK? 154
Size / Dimension 0.383Lx0.198W x 0.150 H 9.73mmx5.03mmx3.81mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Resistance 22.7mOhm
Terminal Finish Matte Tin (Sn)
Color White
HTS Code 8536.10.00.40
Voltage - Rated DC 125V
Packing Method TAPE AND REEL
Depth 5.03mm
Current Rating 3A
Reference Standard CSA; METI; PSE; UL
Voltage - Rated AC 125V
Approval Agency PSE, UL
Body Length or Diameter 9.73mm
Physical Dimension 9.73mm x 5.03mm x 3.81mm
Working Voltage 125V
Power Dissipation 125W
Response Time Fast Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 50A
Melting I2t 1.65
DC Cold Resistance 0.0227Ohm
Circuit Protection Type ELECTRIC FUSE
Fuse Current 3A
Dimensions
Height 3.81mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
