BK/MDA-V-25A image
Favorite
BK/MDA-V-25A image
Favorite
RoHS
/
Package 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Category Circuit Protection / Fuses
Description Cartridge Fuses 250V 25A Time Delay Ceramic
PDF
/
Inventory: 9746
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Mounting Type Through Hole
Package / Case 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Terminal Shape PIN WIRE

Technical

Packaging Bulk
Published 2007
Series MDA
Size / Dimension 0.266Diax1.292L 6.76mmx32.82mm
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Voltage - Rated DC 125V
Current Rating (Amps) 25A
Voltage - Rated AC 250V
Approval Agency CSA, UL
Body Length or Diameter 6.76mm
Physical Dimension 6.76mm x 32.82mm
Response Time Slow Blow
Fuse Type Cartridge, Ceramic
Breaking Capacity @ Rated Voltage 1.5kA AC 10kA DC
Rated Current 25A
Melting I2t 667.9
DC Cold Resistance 0.00309Ohm
Circuit Protection Type Electric Fuse
Blow Characteristic TIME LAG

Dimensions

Body Height 32.82mm

Compliance

RoHS Status Non-RoHS Compliant
