BK/GMA-600MA
RoHS
/
Package 5mm x 20mm
Category Circuit Protection / Fuses
Description
Fuse Miniature 0.6A 250V Fast 2-Pin Cartridge Holder Cardboard Carton
PDF
/
Inventory: 2535
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Holder
Package / Case 5mm x 20mm
Surface Mount NO
Terminal Shape PIN WIRE
Mounting Feature THROUGH HOLE
Technical
Packaging Bulk
Published 2007
Series GMA
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish TIN
HTS Code 8536.10.00.40
Current Rating (Amps) 600mA
Packing Method BOX
Reach Compliance Code unknown
Reference Standard UL; CSA
Voltage - Rated AC 250V
Approval Agency CCC, CSA, MITI, UL
Body Length or Diameter 5.54mm
Physical Dimension 5.54mm x 21.1mm
Response Time Fast Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 35A
Rated Current 0.6A
Melting I2t 0.32
DC Cold Resistance 0.256Ohm
Circuit Protection Type ELECTRIC FUSE
Dimensions
Body Height 21.1mm
Compliance
RoHS Status Non-RoHS Compliant
Alternative Model
