BK/ABC-BV-30-R
RoHS
RoHS compliant
RoHS compliantPackage 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Category Circuit Protection / Fuses
Description
FUSE CERM 30A 250VAC 125VDC 3AB
PDF
/
Inventory: 1859
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 31.75mm
Technical
Fuse Current 30A
DC Cold Resistance 0.002225Ohms
Melting I2t 1429
Breaking Capacity @ Rated Voltage 200A AC 400A DC
Fuse Type Cartridge, Ceramic
Response Time Fast Blow
Max Voltage Rating (DC) 125V
Max Voltage Rating (AC) 125V
Approval Agency CSA, UL
Voltage - Rated AC 250V
Current Rating 30A
Current Rating (Amps) 30A
Voltage - Rated DC 125V
Voltage - Rated 125V
Composition Ceramic
Resistance 2.225mOhm
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.266Diax1.292L 6.76mmx32.82mm
Series ABC
Published 2009
Packaging Bulk
Physical
Body Material Ceramic
Weight 3.628739g
Number of Pins 2
Package / Case 3AB, 3AG, 1/4 x 1-1/4 (Axial)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 13 Weeks
