SF-0603FP125F-2
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Circuit Protection / Fuses
Description
0603 SMD FAST-ACTING PRECISION T
PDF
/
Buying Options
Total Price: USD $0.52
Unit Price: USD $0.52108
≥1 USD $0.52108
≥10 USD $0.491586
≥100 USD $0.46376
≥500 USD $0.437509
≥1000 USD $0.412749
Inventory: 1101
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Surface Mount YES
Terminal Shape WRAPAROUND
Technical
Operating Temperature -55┬?C~90┬?C
Packaging Tape & Reel (TR)
Series SinglFuseō?ó SF-0603FPxxxF
Size / Dimension 0.063Lx0.032W x 0.012 H 1.60mmx0.81mmx0.30mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Additional Feature INTERRUPTING CURRENT-MAX(DC): 13 A, PRE ARCING TIME: OPEN WITHIN 5 SEC AT 200% RATED CURRENT
Current Rating (Amps) 1.25A
Packing Method TR, 7 INCH
Base Part Number SF-0603
Reference Standard UL
Voltage - Rated AC 65V
Approval Agency UL
Body Length or Diameter 1.6mm
Body Breadth 0.81 mm
Physical Dimension 1.6mm x 0.81mm x 0.3mm
Response Time Fast Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 13A AC 35A DC
Rated Current 1.25A
Melting I2t 0.052
DC Cold Resistance 0.048Ohm
Circuit Protection Type ELECTRIC FUSE
Rated Voltage(DC) 65V
Dimensions
Body Height 0.3mm
Compliance
RoHS Status ROHS3 Compliant
